Zhejiang Jiu Kun Technology Co., Ltd.
4 Years
| Ask Lasest Price | |
| Brand Name : | ZhenHua |
| Model Number : | EMF8507 |
| Price : | $240.00 - $470.00/Sets |
Display | 3-line English LCD display; directly shows the data of forward and
reverse flow, percentage of the flow, and flow velocity. |
Parameter Setting | Set the parameter with the button. |
Language | Chinese, English |
Current Output | 4-20mA, Load Resistance ≤ 500Ω (can choose with HART protocol ) |
PIO | Choose passive pulse output, active pulse output, state output, or
alarm output |
Passive pulse output 30VDC(Off), 200mA(On); 0.0001~5000HZ; pulse
width: 50%; duty cycle or the fixed value(≤100ms) | |
Active pulse output 0.0001~2HZ,≤150mA,15VDC±20%; pulse width:≤100ms
(The default value: 20ms) | |
Contact capacity: 30VDC(Off), 200 mA(On) | |
Communication | RS485(MODBUS-RTU, MODBUS-ASCⅡ) |
Power Supply | 220VAC, 24VDC, 100-240VAC |
Alarm | Empty pipe alarm, reverse alarm, upper limit and lower limit alarm. |
Protection Level | IP67 |
Accuracy | 0.5, 0.3 |
Structure | Integrated type, split type |
Application | All conductive liquids, including water, beverage, various
corrosive media, and liquid-solid two-phase fluid (mud, paper
pulp). |
Diameter | DN3~DN2000 |
Pressure | 0.6~4.0MPa (Depend on the different diameters, reference sheet 1,
special pressure can be customized). |
Electrode Material | SS316L, Hc, Hb, Ti, Ta, W, Pt |
Lining Material | Ne, PTEE, PU, FEP, PFA |
Temperature | -40~180 ℃ (Note: limited by the lining material's temperature
resistance; for reference, see “Lining Material Selection” sheet). |
Shell Material | Carbon steel (stainless steel can be customized). |
Protection Level | IP65, IP67, IP68 |
Connection | GB/T9119-2010 (Can connect with HG20593-2009 flange
directly),JIS,ANSI or customized. |
Material | Code | Performance of Corrosion Resistance |
316L | V | Used in industrial water, domestic water, sewage, neutral solution,
and weak acids (carbonic acid, acetic acid, etc). |
Hastelloy Alloy C | Hc | Applicable to oxidation resistance acids, such as nitric acid,
mixed acid, and chromic acid mixed with sulfuric acid. Good corrosion resistance to seawater, alkali solution, and chloride solution. Inapplicable to hydrochloric acid and Hydrofluoric acid. |
Hastelloy Alloy C | Hb | Good corrosion resistance to non-oxidative acid, alkali, salt. Inapplicable to nitric acid. |
Ti | Ti | Good corrosion resistance to sea water,chloride,hypochlorite and
various hydroxides. Inapplicable to reducing acids (hydrochloric acid, sulfuric acid, hydrofluoric acid, etc). |
Ta | Ta | Mostly resistant to the corrosion of all chemical media; generally
used for hydrochloric acid and sulfuric acid. Inapplicable to hydrofluoric acid, alkali, and fuming sulfuric acid. |
Tungsten Carbide | W | Good wear resistance; used for the wearing media, such as mud and
paper pulp. Poor corrosion resistance. |
Platinum-iridium Alloy | Pt | Except for aqua acid and ammonium salt, it is mostly resistant to
the corrosion of all of the acidic, alkaline, and salt solutions |
Material | Performance of Corrosion Resistance | Working Temperature | Applicable Areas | Diameter (mm) |
PTFE | Mostly resistant to the corrosion of all chemical media. | -40~150℃ | All media, except the fluid in negative-pressure pipe and fluids
with good wear resistance | DN15~1200 |
NE | Corrosion resistance to low consistency acid,alkali and
salt,besides oil. | -30~80℃ | Industrial water, sewage, low consistency acid, alkali, and salt
solutions. | DN50~2000 |
FVMP | Corrosion resistance to low consistency acid,alkali and salt. Resistant to high temperature and negative pressure. | -30~150℃ | Industrial water, sewage, hot water, low consistency acid, alkaline
and salt solutions. | DN50~2000 |
PU | Good wear resistance; used for the wearing slurry. Poor corrosion resistance. | -30~80℃ | Liquid containing solid grains (grout,slurry) | DN15~400 |
FEP | The corrosion resistance is equal to that of PTFE | -40~150℃ | All fluids, except the wearing media (mortar, etc). | DN3~400 |
PFA | Corrosion resistance to all chemical media,The temperature
resistance is better than FEP. | -40~180℃ | Same as PTFE; preference for sustained high temperature. | DN3~400 |
|
|
